Product indication - Type/Concept/Collection

Design variants: Wall-to-wall

Ege CircleBack is a unique carpet recycling program where we offer to take back your used carpets in Europe for recycling. We divide the used carpets into 3 fractions. The yarn and glue/coating are used again in our own products and the last fraction is used to produce recycled plastic. Read more details about Ege CircleBack here.

The program covers the qualities Highline 1100 and Highline 910 with the woven textile backing (WT).

The Highline Express Graphic Collection covers a myriad of predesigned patterns inspired by geometry, hoops, stripes, 3-dimensional grids and expressive typography. In contradiction, the collection also offers simply beautiful mélanges and random abstracts. Ranging from bold and dramatic designs to organic, fluid and distorted patterns, the Graphic Collection provides a powerful design language to tell your story on the floor. Thanks to our advanced production technology, it is easy and quick to recolour standard designs at no extra charge.

Thank you for your request!

We are preparing your digital files pack and you will receive an email shortly with a link to download.

Meanwhile, you can select and order free physical samples from your configuration that can be shipped to you.

{{ title }}

We are sorry, we could not get data from one or more of the products.

Recoloured

Choose quality

Chosen: {{selectedQuality.title}}
{{item.title}}

Choose backing

Chosen: {{selectedBacking.title}}
{{item.title}}

Choose sample size

Chosen: {{selectedSize.title}}
{{item.title}}
When you have chosen a quality and a backing, the available sample sizes will be shown here.

Recoloured

Choose sample

Chosen: {{selectedRelated.title}}
{{item.title}}

Guides and images

Order sample folder

Choose sample folder

Chosen: {{selectedArchitectFolder.title}}
{{item.variantId}}
{{item.title}}

Product specifications

{{toolTip.title}}
{{item.subtitle}}: {{item.text}} {{item.text}}
{{toolTip.paragraph.title}}
{{toolTip.paragraph.text}}
{{toolTip.linkText}}

Specifications
based on

orbit grey
Quality: {{selectedQuality.preTitle}}
Backing: {{selectedBacking.preTitle}}

Quality

{{item.title}}
Read more

Backing

{{item.title}}
Read more
Certificates & markings
Xantistat Xstairs 1307_32 cert_eng MER imo0575_03 bfl_s1 ce14041 VOC_1 C2C_Bronze
Construction characteristics
Structure ISO 2424 Tufted cut pile
Gauge ISO 2424 1/8
Pile material DIR 96/73, 96/74 80% wool, 20% polyamide
Coloration - Millitron dyed
Backing ETL AB - Acoustic backing
Dimensions CEN/TS 14159 Approx. 400 cm
Total thickness ISO 1765 Apr 11,0 mm.
  . 0.43"
Surface pile thickness ISO 1766 Apr 6,5 mm.
Tufts ISO 1763 Apr 136.000 pr.m2
Total carpet weight ISO 8543 Apr 3.100 g/m2
  . 91.45 oz./yd2
Pile yarn weight ETL 1.400 g/m2
  . 41.3 oz./yd2
Surface pile density ISO 8543. Apr 0,155 g/cm3
Biocidal treatment Biocidal Product Regulation Contains preservative to control
. . microbiological deterioration
Performance characteristics
Performance areas EN 1307 Class 32 Commercial - General
Guarantee ETL Contract certificate
Performance areas Gulvbranchen Class 32
Suitability for use on stairs EN 1963 Yes
Static control ETL Permanently antistatic
Body walking test EN 1815 Antistatic
Acou.insu. from impact noise ISO 717-2 41 dB
Acoustical absorption ISO 354 0,35 aW
Thermal insulation ETL Apr 0,19 m2K/W
Light reflectance ETL Testreport
Colour fastness to light ISO 105-B02 >4
  AATCC 16 4.5
Colour fastness to rubbing wet ISO 105-X12 >3
Colour fastness to rubbing dry ISO 105-X12 >3-4
Colourfast. to water patterned ISO 105-E01 >4
Safety & Environment
Fire classification MER Certified
  MER Certificate No. MERB000016J
  IMO Certified
  USCG 164.117/EC0575/MEDB000016J
  EC Type-Ex.Cert.No. MEDB000016J
  QS-Cert.of.Assesment-EC No. MEDD000001V
  Declaration of Conformity DOC-MEDB000016J
  ASTM E-648 Class 1
  ASTM E662 Smoke Density <450
  ASTM D2859 Surface Flamm. Pass
  EN 13501-1 Euroclass Bfl-s1
  Transport Canada Suitable
  ASISO 9239.1-2003 9,40 KW/m2
  RUSSIA Approved
CE Labeling EN 14041 Certified
  CPR 1021-CPR-014-1/16
  Declaration of Performance DOP 3B-WO/PA-AB
  Notified body no. 1021
  Ce Year 07
  Content of PCP DL
  Formaldehyde emission NA
  Slip resistance Class DS
Indoor climate Green Label Plus Approved
  DCL Attestation of Conformity Product complies
  Emissions dans l'air intérieur A+/A+
  Indoor Air Comfort Gold Group 4
  ABG ABG-28-01-04-02-2018
Environment Byggvarudeklaration eBVD
  BASTA Registered
  Byggvarubedömningen ID 148786
  SundaHus score B
  BREEAM International Approved
  BREEAM-NOR Approved
  Environmental Product Decl. MD-21075-EN
  Cradle To Cradle Certified Bronze certified
  Recycled Content, ISO 14021 Apr 13,0 %
  Recycled Content for LEED Apr 8,0 %
  ECOproductNorway Approved
  LEED Qualified
  GWP Cradle to Gate (A1-A3) 16,70 KgCO2eq/m2
  GWP Cradle to Grave (A-C) 24,32 KgCO2eq/m2
Guides
Installation + adhesive guide DK Dansk
  N Norsk
  S Svensk
  GB English
  D Deutsch
  F Francais
Cleaning, stain removal DK Dansk
  N Norsk
  S Svensk
  GB English
  D Deutsch
  F Francais
Manufacturer characteristics
Factory certification ISO 9001 Audited and verified by BVC
  ISO 14001 Audited and verified by BVC
  ISO 45001 Audited and verified by BVC
  CRuk Member of Carpet Recycling UK
