Product indication - Type/Concept/Collection

Design variants: Wall-to-wall

Attention to detail is paramount, especially when it comes to conveying luxury. The word graphic is used to mean clear and vivid detail and this aspirational collection of petite patterns is eye-catchingly attention-grabbing.
Our refined Graphic concept is available in a choice of desirable designs and carefully selected colour palettes. But to tell the story you want to tell in your own way, you need to create your own individual design. Patterns help to create a visual rhythm that promotes harmony within our surroundings, and the soft-underfoot Graphic concept is perfect for making that all important sensorial design statement.
Available in widths of four or five metres, to help reduce wastage and seams, resulting in an overall superior installation. Ideal for pattern repeats not exceeding 10x10 cm, our Graphic collection is available in any colour imaginable, to complement your interior.

Thank you for your request!

We are preparing your digital files pack and you will receive an email shortly with a link to download.

Meanwhile, you can select and order free physical samples from your configuration that can be shipped to you.

{{ title }}

We are sorry, we could not get data from one or more of the products.

Recoloured

Choose quality

Chosen: {{selectedQuality.title}}
{{item.title}}

Choose backing

Chosen: {{selectedBacking.title}}
{{item.title}}

Choose sample size

Chosen: {{selectedSize.title}}
{{item.title}}
When you have chosen a quality and a backing, the available sample sizes will be shown here.

Recoloured

Choose sample

Chosen: {{selectedRelated.title}}
{{item.title}}

Guides and images

Graphic folder

Order sample folder

Choose sample folder

Chosen: {{selectedArchitectFolder.title}}
{{item.variantId}}
{{item.title}}

Product specifications

{{toolTip.title}}
{{item.subtitle}}: {{item.text}} {{item.text}}
{{toolTip.paragraph.title}}
{{toolTip.paragraph.text}}
{{toolTip.linkText}}

Specifications
based on

Graphic 80/20 serrated
Quality: {{selectedQuality.preTitle}}
Backing: {{selectedBacking.preTitle}}

Quality

{{item.title}}
Read more

Backing

{{item.title}}
Read more
Certificates & markings
Xantistat 1307_32 5yr_dk_slid imo0575_03 bfl_s1 ce14041 C2C_Bronze
Construction characteristics
Structure ISO 2424 Tufted cut pile
Gauge ISO 2424 1/8
Pile material DIR 96/73, 96/74 80% wool, 20% polyamide
Coloration - Pre-dyed
Backing ETL LWT - Laminated woven textile
Dimensions ISO 3018 Approx. 400/500 cm
Total thickness ISO 1765 Apr 8,0 mm.
Surface pile thickness ISO 1766 Apr 6,0 mm.
Tufts ISO 1763 Apr 120.700 pr.m2
Total carpet weight ISO 8543 Apr 1.720 g/m2
Pile yarn weight ETL 1.300 g/m2
Surface pile density ISO 8543. Apr 0,123 g/cm3
Performance characteristics
Performance areas EN 1307 Class 32 Commercial - General
Guarantee ETL Wear guarantee 5 Years
Static control ETL Permanently antistatic
Body walking test ISO 6356 Antistatic
Colour fastness to light ISO 105-B02 >5
  AATCC 16 5.0
Colour fastness to rubbing wet ISO 105-X12 >3
Colour fastness to rubbing dry ISO 105-X12 >3-4
Colourfast. to water patterned ISO 105-E01 >2-3
Colour fastness to ozone AATCC 129 5.0
Safety & Environment
Fire classification IMO Certified
  USCG 164.117/EC0575/MEDB000017X
  EC Type-Ex.Cert.No. MEDB000017X
  EN 13501-1 Euroclass Bfl-s1
CE Labeling EN 14041 Certified
  CPR 1021-CPR-085-1/22
  Declaration of Performance DOP 6B-WOPA-LWT
  Notified body no. 1021
  Ce Year 07
  Content of PCP DL
  Formaldehyde emission NA
  Slip resistance Class DS
Indoor climate Green Label Plus Approved
  Indoor Air Comfort Gold Group 17
Environment Byggvarudeklaration eBVD
  Byggvarubedömningen ID 150473
  SundaHus score B
  BREEAM-NOR Approved
  Cradle To Cradle Certified Bronze certified
  Recycled Content, ISO 14021 Apr 0,0 %
  Recycled Content for LEED Apr 0,0 %
Guides
Installation + adhesive guide DK Dansk
  N Norsk
  S Svensk
  GB English
  D Deutsch
  F Francais
Cleaning, stain removal DK Dansk
  N Norsk
  S Svensk
  GB English
  D Deutsch
  F Francais
Manufacturer characteristics
Factory certification ISO 9001 Audited and verified by BVC
  ISO 14001 Audited and verified by BVC
  ISO 45001 Audited and verified by BVC
  DS 49001 Audited and verified by BVC
  CRuk Member of Carpet Recycling UK
